Grooved Stator Inslot Automatic Coil Winding Machine For Stepping Motor

Grooved Stator Inslot Automatic Coil Winding Machine for Stepping Motor
The winding track of this inslot winding machine is in a rectangle shape, which greatly improves machine productivity and winding quality.

(1)Specification

Wire diameter0.08~1.0mm
Stator IDMin 19mm
Stack length7~90mm
Turn No.0~9999
MovementStepping/Auto
Slot number6,8,9,10,12,14,18(customized)
Air source5~7kg/cm3
Power2KW
Power supplyAC 220 V, 50/60HZ
Weight450KG
Dimension1600x1100x1400mm


(2)Application
Suitable for various types of multi-poles stators, stepping motor, BLDC motor regardless of wire diameter.

(3)Features
Rectangle winding track
Fully programmable operation
Can meet high winding requirements
Precision performance of needle winding
Quick change-over of tooling
Suitable for stators with narrow slot width but high slot filling rate

(4)Machine configuration
Mitsubishi PLC
Touch screen
AIRTAC cylinder
Delta AC servo system and dual spindle synchronous control unit
Lubrication system
