Fully-Automatic-8-Working-Stations-Stator-Coil-Winding-Machine

Basic Info.

Model NO.

WIND-800-VW

Specification

Middle Size

Trademark

Wind Automation

Origin

China

HS Code

8479811000

Production Capacity

100 Sets/Year

Product Description

Fully Automatic 8 Working Stations Stator Coil Winding Machine

This machine adopts turntable mechanism. After one coil wound, the turntable will rotate to swith working station. Therefore, four station will do winding, while the other four wait for unloading, which greatly improves the working efficiency.

(1) Specification

(2) Feature
4 winding head 8 working station
Manual unloading coils after winding
Rotation and indexing controlled by servo system
No distinct vibration or noise during winding
Automatically stop if wire is run out
All winding parameter programmable on touch screen

(3) Application
This machine is suitable for 2 poles, 4 poles and 6poles coils winding.

(4)Operation step
Thread wire into the machine
Connect the power and air source
Turn on the machine, and press "reset" button to reset the machine
Put the winding form on the indexing plate
Press "cut wire"
Press "start" button by two hands, machine will automatically wind the stator.
