Stator Coil Winding and Coil Inserting Machine

Automatic Stator Coil Winding and Coil Inserting Machine

This machine is equipped with 4 working stations, two for winding, one for wedge cutting, one for coil insertion.It is suitable for stators with high slot filling rate.


(1) Specification

Stator ID40~100mm
Stator ODMax 160mm
Stack length20~100mm
Tooling strokeMax 110mm
Suitable wire materialCopper/Aluminium wire
Slot number16~36slots
Power22KW
Weight3500KG
Dimension1250x1800x2350mm


(2) Application
This type of machine is suitable for small type AC motor, induction motor stators.

(3) Feature
Four working station
Can do both coil winding and coil inserting
Manual loading and unloading

Can be customized accordingly
Parameter of different models can be edited, modified and displayed
Quick and easy readjustment for other types of stator
Copper wire and aluminium wire are both applicable
Easy for operation, No skilled operator required
