BLDC-Motor-Stator-Slot-Paper-Inserter-Paper-Insertion-Machine

Product Description

Rotor Slot Paper Inserter Paper Insertion Machine

This machine is consisted of one set 0.75KW motor, one reducer with brake, one set of paper feeding belt and feeding box composed of knurled gears, one set tooling, a cabinet as well as body frame.

This machine adopts full mechanized action. The feeding box feeds insulation paper into the tooling, equipped with a tooling bottom, punching needles, and a cutter. When the paper is sent to the position,  paper cutter cuts the paper and pushes it into the bottom of the tooling. Next, needle punches down, presses the paper into the tooling, squeezes it, then punch it up, so as to insert formed paper into workpiece body. After that, needle returns, the divider rotates, the gear moves forward. One slot is finished, then insert the second slot. Machine is equipped with an induction switch on the rotating shaft, and it will automatically stop after one cycle.

This machine can do automatically paper inserting, loading and unloading are done by manual. Paper roll will be needed to do paper inserting. The width should be equal to workpiece stack length.

This machine is suitable for workpiece with 8 ~48 slots. It can do auto paper feeding, forming and angle turning. Paper should be inserted into slot properly.
