Induction cooker production line for R99_170 Bobin

This induction cooker bobin production line is designed for ensuring high production efficiency, consistence quality of induction cooker with necessary machines and workers

The major process:

Litz wire winding→Bobin inductor winding→Place terminal →Welding→Place magnet→Thermosealing →Testing

Litz wire Winding Machine WIND-650P-LW

Frame enough for Ø 0.27 mm x 66 wires      Reels 5pcs included in machine price

Main Features:

1. The spindle (main shaft) was done high frequency heater treatment and balancing process

      which ensure the litz wire winding quality

   2. Magnetic tension device control the placement of wire safely to reels



   Technical  Parameter:
   Wire diameter:  0.10~1.00 mm (copper or aluminum)

   Coil square meter:0.18~6.7mm2
   Max speed:   1500RPM
   Motor power:  7500W SIEMENS

   Ball bearing:NSK

   Relay: Omron
   Voltage:  three phase AC  380V   50/60 Hz
   Weight:  3000Kg
   Dimension: 2800(length)X1200(width)X1450(height)mm　

   Color per customer requirement  (http://www.ralcolor.com/ )

















   Induction coil winding machine WIND-RXJ-2



   Machine put in wire and cut wire automatically which can save wire cost

Main motor: 1000W servo motor,220V

Spindle speed:0~5000RPM

Array motor: Stepper motor

Z axis nozzle: Stepper motor

Wire diameter:0.3~5.0mm

Max coil disk: 350mm

Max Stroke: X axis 250mm , Z axis  80mm

Power:2000W

Cycle time: 300pcs/Hour

Dimension: 800*600*1100mm

Terminal placement machine WIND-YDZ-1

Crimp capacity: 40KN

Opening height: 220mm

Stoke: 170PSM

Power:1500W

Cycle time: 1200PCS/Hour

Weight:105KGS

Dimension: 300*290*780mm

Welding  WIND-HJ-1

Place magnet

Thermosealing (Hot melt press with cylinder or

                servo motor type WIND-ICP-S)

Gas-liquid boosting cylinder type

Air source: 0.4MPa

Gas-liquid booster pump: 5Ton

Power:2000W

Net Weight: 100KGS

Dimension:800*600*1900mm

Testing machine WIND-CS-1

Test the finished coil disk of induction heater,similar as transformer testing

Testing machine is mainly test the inductance,DC resistance and Q value of the induction cooker coil disk,and other content and parameter ( Indutance, Q, or some other parameter)

User need to inform tesing frequency range 1K HZ or 10K HZ
